The R&S RT-ZISO system enables accurate measurements of fast switching signals, especially in environments with high common-mode voltages and currents, according to the company. Its R&S RT-ZPMMCX passive probe with MMCX connector is also a new addition, designed to complement the system for low-side gate measurement tasks.
Rohde & Schwarz said the R&S RT-ZISO provides precise differential measurements of up to ±3 kV on reference voltages of ±60 kV with a rise time of < 450 ps and suppresses fast common-mode signals that can distort and interfere with accurate measurements. The power-over-fibre architecture galvanically isolates the device under test from the measurement setup, providing a much higher common-mode rejection ratio than conventional differential probes, noted the company.
Key features include bandwidth options of 100 MHz to 1 GHz (upgradeable), a CMRR of > 90 dB (> 30 000:1) at 1 GHz, an input and offset range of ±3 kV, a common mode range of ±60 kV, and a sensitive input range of ±10 mV.
The company claimed that with the next generation MXO series (MXO 4, MXO 5 and MXO 5C), the probe enables measurements with the “world’s fastest acquisition in the time and spectrum domain”, thanks to the oscilloscopes’ hardware-based acceleration. In combination with the R&S RTO6, design engineers can use the probe for complex analysis tasks using the oscilloscope’s “high performance and advanced measurement capabilities”.
R&S RT-ZISO is designed for various applications, including switching analysis of power converters with WBG materials, double-pulse testing, floating measurements, shunt measurements, inverter design and motor drive analysis.
PCIM Europe, an international event for power electronics and its applications, was held in Nuremberg, Germany from June 11 to 13.
